S355JOWP Steel

Corrosion resistant steel plate S355J0WP under standard EN 10025-5 is mainly used for container steel.Flat products made of S355J0WP steel have the condition of delivery Normalized rolled.Between S355J0WP and S355J2W,S355J2WP contains more P in chemical composition.If mechincal properties have been significantly modified by heavy cold forming,either stress relief annealing or normalized may be applied.

Quick inquiry

E-mail

PRODUCT DISPLAY

We can not only provide you with ordinary steel, but also help you find very personalized steel, such as special steel, special size, special process shape and so on.

Technical Requirements & Additional Services:

Low temperature impacting test
Cutting and welding as per end user's demands
More striction on some chemical elements contains
Ultrasonic test under EN 10160,ASTM A435,A577,A578

Product: Hot rolled steels with improved atmospheric corrosion resistance
Grade: EN10025-5 S355J0WP
S355J0WP steel applicable thickness or Diameter: Plate ≤150mm, Sections/shapes ≤40mm,
S355J0WP steel applicable delivery product: S355J0WP steel plates, S355J0WP steel strip in coil, S355J0WP steel sheet, S355J0WP steel Shapes, S355J0WP section steels,
S355J0WP delivery condition: Normalizing rolling (+N), As rolled (+AR)
S355J0WP Weathering steel chemical composition

Grade	Material No.	C max	Si max	Mn	P max	S max	N max	Cr max	Cu max
S355J0WP	1.8945	0.12	0.75	1.0	0.06-0.15	0.035	0.009	0.30-1.25	0.25-0.55

S355J0WP Normalized steel Mechanical properties in room temperature

Grade

Material No.

Min Yield strength in different thickness

Min tensile strength in different thickness

Elongation in different thickness

≤
16

>16
≤40

>40
≤63

>63
≤80

>80
≤100

>100
≤150

≤
3

>3≤
100

>100≤150

≤1.5

>2≤2.5

>2.5≤3

>3
≤40

>40
≤63

>63
≤100

>100≤150

S355J0WP

1.8945

355

345

510-
680

470-
630

Mechnical property for S355J0WP Corten steel:

Thickness (mm)
S355J0WP	≤ 16	> 16 ≤ 40	> 40 ≤ 63	> 63 ≤ 80	> 80 ≤ 100	> 100
Yield strength (≥Mpa)	355	345	345	345	345	345
	< 3	≥ 3 ≤ 100				> 100
Tensile strength (Mpa)	510-680	470-630				470-630

Chemical composition for S355J0WP Corten steel (Heat Analysis Max%)

Main chemical elements composition of S355J0WP
C	Si	Mn	P	S	N	Cr	Cu
0.12	0.75	1.00	0.06-0.15	0.035	0.009	0.30-1.25	0.25-0.55
